80W, 10GHz, 3cm - Microwave Power Amplifier (OSC1243-1)

Prezzo di listino
Prezzo scontato
Tasse incluse.
La quantità deve essere 1 o più

High Reliability Microwave PA, designed with last generation GaAs devices.

Single power supply, ready to be mounted on heatsink (mandatory).

Typical output power of 80W typ @ 10.3GHz

Full data sheet available upon request.

Available in 8-12wks from the order.


  •  Frequency: 10.3-10.4GHz
  •  Input power: 200mW typ
  •  Supply Voltage: 11.0-15.0 Volt (internal DC-DC), optimized for 13,8Volt

ps: in case of RF components (own produced by our partner) damage inside the unit (tipically for un correct connection of the unit, overdrive ecc) we are able to repair it.
